รายละเอียดสินค้า:
|
| เน้น: | heavy duty steel floor grating,hot dip galvanized steel grate,industrial steel bar grating |
||
|---|---|---|---|
| 15-w-4 | Bearing Bars at 15/16" O.C. Cross Bars at 4" O.C. | 15-w-2 | Bearing Bars at 15/16" O.C. Cross Bars at 2" O.C. |
|---|---|---|---|
| 19-w-4 | Bearing Bars at 1-3/16" O.C. Cross Bars at 4" O.C. | 19-w-2 | Bearing Bars at 1-3/16" O.C. Cross Bars at 2" O.C. |
| 22-w-4 | Bearing Bars at 1-3/8" O.C. Cross Bars at 4" O.C. | 22-w-2 | Bearing Bars at 1-3/8" O.C. Cross Bars at 2" O.C. |
| 30-w-4 | Bearing Bars at 1-7/8" O.C. Cross Bars at 4" O.C. | 30-w-2 | Bearing Bars at 1-7/8" O.C. Cross Bars at 2" O.C. |
| 38-w-4 | Bearing Bars at 2-3/8" O.C. Cross Bars at 4" O.C. | 38-w-2 | Bearing Bars at 2-3/8" O.C. Cross Bars at 2" O.C. |
| Traffic Type | Wheel Load (Ibs) (1/2 axle load +30% Impact) |
Load Distribution Parallel With Axle |
Perpendicular to Axle |
|---|---|---|---|
| H-25 Truck Traffic 40000lb.Axle Load Dual Wheels Modified AASHTD H-25 |
26,000 | 2(C)+25" | 25" |
| H-20 Truck Traffic 32000lb.Axle Load Dual Wheels Modified AASHTD H-20 |
20,800 | 2(C)+20" | 20" |
| H-15 Truck Traffic 24000lb.Axle Load Single Wheels Modified AASHTD H-15 |
15,600 | 2(C)+15" | 15" |
| Automobile 6322 Ib Vehicle 3578 Ib.Load 60%Drive Axle Load |
3,861 | 2(C)+9" | 9" |
| 5Ton Forklift 10000 Ib.Cap.LiftTruck 14000Ib.Vehicle 24,000 Ib.Table Load 85% Drive Axle Load |
13,480 | 2(C)+11" | 11" |
| 3Ton Forklift 6,000 Ib.Cap.Lift Truck 9000Ib.Vehicle 15800 Ib.Table Load 85% Drive Axle Load |
8.730 | 2(C)+7" | 7" |
| 1Ton Forklift 2,000 Ib.Cap.Lift Truck 4200Ib.Vehicle 6200 Ib.Table Load 85% Drive Axle Load |
3,425 | 2(C)+4" | 4" |
